Product Introduction
Guanyu Company combines advanced technologies at home and abroad, adopts UV, photocatalysis, 0 3 , advanced oxidation, high-efficiency mixing, refrigeration and other technologies, and develops and produces a new generation of products AOP products (the oxidation process with hydroxyl free radicals as the main oxidant in the water treatment process is called AOPS, abbreviated as AOP). This product uses UV nano-photocatalysis + ozone technology + advanced oxidation technology to form hydroxyl free radicals (0H AOP is a water treatment product that uses hydroxyl radicals to efficiently oxidize organic matter in water. It also thoroughly and efficiently decomposes organic matter, microorganisms, pathogens, sulfides, phosphides, etc. in water to achieve the requirements of water deodorization, disinfection, sterilization, and purification. The treated water quality meets the relevant national standards. AOP products solve the problems of single water treatment methods and win the favor of the market and users with their unique technical combination advantages.
Product technical features
★ Easy to install and saves floor space.
★ Reliable cooling system: The equipment's cooling system and air source system have controllable and adjustable temperatures
★ High ozone production efficiency and high concentration: ozone concentration is greater than 120mg/L.
★ Highly efficient mixing, micro-nano bubbles, high solubility, large diffusion coefficient of solute and dispersed phase storage capacity.
★ High-intensity special ultraviolet technology instantly produces hydroxyl free radicals.
★Nano high-efficiency catalysis, instant decomposition and oxidation of organic matter.
★ Rapid, efficient and non-selective reaction. The treated water can achieve rapid oxidation of organic matter at the moment of entering and leaving the equipment. The effluent COD meets the new national emission standards or the requirements for recycled water reuse.
★Can completely degrade organic matter into carbon dioxide, water will not produce secondary pollution, effectively increase the transmission speed and contact time of ozone in water to enhance the utilization efficiency of ozone, save ozone dosage and oxidation time, thus greatly saving ozone equipment investment and operating costs
★The filling of the fixed bed heterogeneous catalyst bed and the development of loaded rare metal heterogeneous catalysts strengthen the gas-liquid two-phase mass transfer and increase the reaction rate. It has the characteristics of long replacement cycle and small filling amount, which can effectively increase the ozone utilization rate by more than 15%.
★The reaction system also has auxiliary functions such as sterilization, anti-scaling, decolorization, and COD removal.
Application Industry
Guanyu AOP water purification equipment adopts UV photocatalysis + ozone + advanced oxidation technology. The products can be applied to secondary water supply, river management, black and smelly water bodies, swimming pools, surface water, landscape water, aquaculture and other water treatment systems.
Product Advantages
★ High concentration ozone system
130mg/, to ensure that the swimming pool water quality meets the standards in a long-term and stable manner .
★ Customized soda double cooling intelligent system
The air source cooling system ensures that the ozone air intake is kept constant and dry, and is not affected by external weather changes and ambient temperature, ensuring continuous operation of ozone at a high concentration; the cooling water cooling system saves cooling water. Using a 300G ozone generator can save nearly 10,000 yuan of cooling water each year, and it has the function of automatically setting the air source temperature and cooling water temperature .
★ High efficiency mixing system
The efficient combination of 7 processes, including customized anti-corrosion dual-circulation mixing system, nano-level micro-bubble cutting high-efficiency dual-mixing system, special high-efficiency jet mixing system, multiple protection + ozone mixing tank system, etc., makes the ozone mixing efficiency reach 70-80%, and eliminates the destruction system and mixing tank system in the swimming pool process. For a 2,000 cubic meter swimming pool, the ozone destroyer alone can save a one-time investment of 60,000 to 80,000 yuan (2,000 cubic meter water capacity: 6 hours of circulation: 1/4 cubic meter of water volume: 60x4=240 cubic meter stainless steel water tank), and saves a lot of installation space .
★High concentration customized gas production system
Imported medical-grade molecular sieve, outlet concentration 93%. The equipment does not have continuous heating equipment temperature, oxygen temperature is constant, modular structure, compact structure, saving air compressor, cold dryer, drying equipment, pressure tank, etc. space and installation costs. High-intensity, high-power customized nano-high-efficiency photocatalytic system has 3-5 times the efficacy of ordinary photocatalytic equipment, with self-cleaning function, hydroxyl free radical sterilization and purification effect is several times more than that of ozone equipment and ultraviolet equipment alone .
★Intelligent customizable control system
Intelligent control systems and IoT intelligent control systems can be customized according to user and working conditions, and can be linked with the previous and next links of the system. It can also achieve one-button start and unattended operation.
Application Advantages
★ Widely used in various hot springs, swimming pools, paddling pools, water parks, especially suitable for sterilization of swimming pool water for infants and young children.
★ Using UV photocatalytic technology + ozone advanced oxidation technology + ozone high-efficiency mixing technology, no chemical agents are added during the sterilization process, eliminating the harm of traditional disinfection to human skin, eyes and respiratory system.
★ Because no chemical agents are added during the circulating water treatment process, the daily water replenishment volume and backwashing times are reduced, saving 50% of water.
★ Highly efficient control of microorganisms, the sterilization effect is 3-5 times that of a single product.
★ It improves the water quality while improving the air quality of the space, increasing the comfort of swimmers.
★ Reduce the investment in other auxiliary equipment, save installation space cost, installation time cost, and subsequent maintenance cost.
★ We can customize products according to customers' high standards, and use various detection technologies, Internet of Things intelligent control and other technologies to effectively improve service levels and increase swimming pool charges.
Technical Parameters
|
Public adult, competition semi-standard, standard pool swimming pool selection table |
|||||
| Equipment Model | Total water
volume of swimming pool m³ |
A cycle takes
time |
Equipment diameter mm | Circulation
flow m³/h |
Total power kw |
| GYY-AOP-20 | 120-160 | 3-4h | DN100 |
40 |
3.5 |
| GYY-AOP-30 | 180-250 | 3-4h | DN125 |
60 |
5 |
| GYY-AOP-60 | 350-480 | 3-4h | DN150 |
120 |
7 |
| GYY-AOP-100 | 600-800 | 3-4h | DN200 |
200 |
9.5 |
| GYY-AOP-200 | 1200-1600 | 3-4h | DN300 |
400 |
15.5 |
| GYY-AOP-300 | 1800-2400 | 3-4h | DN350 |
600 |
26.5 |
|
Baby pool selection |
|||||
| Equipment Model | Total water volume of swimming pool m³ |
A cycle takes time |
Equipment diameter mm | Circulation flow m³/h | Total power kw |
| GYY-AOP-20 | 40-80 | 1-2h | DN100 |
40 |
3.5 |
| GYY-AOP-30 | 60-120 | 1-2h | DN125 |
60 |
5 |
| GYY-AOP-60 | 120-240 | 1-2h | DN150 |
120 |
7 |
| GYY-AOP-100 | 200-300 | 1-2h | DN200 |
200 |
9.5 |
| GYY-AOP-200 | 400-600 | 1-2h | DN300 |
400 |
15.5 |
|
Private swimming pool selection table |
|||||
| Equipment Model | Total water volume of swimming pool m³ | A cycle takes time | Equipment diameter mm | Circulation flow m³/h | Total power kw |
| GYY-AOP-20 | 250-300 | 6-8h | DN100 |
45 |
3.5 |
| GYY-AOP-30 | 350-450 | 6-8h | DN125 |
60 |
5 |
| GYY-AOP-60 | 700-900 | 6-8h | DN150 |
120 |
7 |
| GYY-AOP-100 | 1200-1500 | 6-8h | DN200 |
200 |
9.5 |
| GYY-AOP-200 | 2500-3000 | 6-8h | DN300 |
400 |
15.5 |
